Ford WSG850
Ford Power Products WSG850 — 5 L V8 spark-ignition genset engine, naturally aspirated, bi-fuel natural gas / LPG. 59.3 kWm (79.5 hp) on natural gas, 65.3 kWm (87.6 hp) on LPG at 1800 rpm (SAE J1349 intermittent); 12:1 compression, EPA/CARB certified with 3-way catalyst.
Production StatusIn Production
WSG
- Configuration
- V8
- Displacement
- 5 L
- Fuel
- Natural Gas
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| Rating | Prime |
|---|---|
| Mechanical power kWm | 59.3 |
| Electrical output kWe | 53 |
| Apparent power kVA | 66.3 |
Datasheet & documents
Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.
Technical specifications
Technical Specifications
| Brand | Ford |
| Model | WSG850 |
| Series | WSG |
| Configuration | V8 |
| Cylinders | 8 |
| Displacement | 5 L |
| Compression Ratio | 12:1 |
| Dry Weight | 205.5 kg |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Stationary |
| Certifications | EPA, CARB, 3-way catalyst |
| Country of Origin | United States |
Check your engine model
The Ford WSG850 is a natural gas generator-drive engine for 60 Hz generator sets, rated at 66 kVA / 53 kWe / prime rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
Other ways this model is written
wsg850Ford WSG850
WSG850 repair parts
Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.
Get a parts & air-shipping quoteIn-stock parts: same-day dispatch
Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.
Find the right part
Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.
Other parts? Add them in the chat.
Get my parts quote on WhatsAppWe’ll confirm the correct parts, stock and delivery cost before you order.
Opens WhatsApp. Attach photos in the chat.
Photos and details to send
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Part-number references
Confirm fitment against your engine serial number.
- Cylinder head gasketJR3Z-6051-E
Fitment details & source
Right cylinder head gasket
Fitment check: The archived source prints complete Ford model WSG850 and exact right cylinder head gasket part number JR3Z-6051-E in one bounded record. Right-side gasket only; confirm engine serial/build and installed head specification before ordering.
Source: EDI WSG850 parts manual
Get help with this engine
Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.
Other ways to contact us
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamNeed help after checking the documents?
Send us the part number or describe the problem. This engine model is included in your message.
Send this model enquiry by emailOr browse Haifeng's gas generator sets
Frequently asked questions
What is the power output of the Ford WSG850?
The Ford WSG850 is rated at 66 kVA prime at 60 Hz (1,800 rpm).
Does the WSG850 run at 50 Hz or 60 Hz?
The Ford WSG850 is rated for 60 Hz (1,800 rpm).
What fuel does the Ford WSG850 use?
The Ford WSG850 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the WSG850?
The Ford WSG850 is a V8 (8-cylinder) engine with a displacement of 5 L.
What emissions information is listed for the WSG850?
This record lists U.S. EPA Stationary for the Ford WSG850. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Ford WSG850?
The Ford WSG850 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the WSG850?
This page links reference documents for the Ford WSG850. Check each document's title, model coverage, revision and rating conditions before using it for selection.
