FPT
F34TEVP02.00
FPT F34TEVP02.00 4-cylinder diesel engine for generator sets. 34.6 kWm prime / 38.5 kWm standby at 60Hz. EPA Tier 4 Final (DOC+DPF+SCR).
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
60 Hz2160 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 34.6 | 31.1 | 38.9 |
| Standby Power | 38.5 | 34.7 | 43.4 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | FPT |
| Model | F34TEVP02.00 |
| Configuration | Turbocharged |
| Cylinders | 4 |
| Displacement | 3.4 L |
| Fuel Type | Diesel |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | Italy |
