Generac
Generac SG080
Industrial Gaseous
Generac SG080 uses the 4.43 L inline-four gaseous engine at 1800 RPM. The official specification publishes 80 kWe standby and 122 hp at rated output. EPA annual certification data records matching 4.4 L inline-four stationary configurations.
- Standby Power · 60 Hz
- 100 kVA
- Electrical Output
- 80 kWe
- Cylinders
- L4
- Displacement
- 4.43 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 73 | 91.3 |
| Standby Power | 91 | 80 | 100 |
Generac SG080 generator set context
The Generac SG080 is listed here as a natural gas generator-drive engine for 60 Hz generator sets, with a headline 100 kVA / 80 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Generac |
| Model | SG080 |
| Series | Industrial Gaseous |
| Configuration | Inline-4 Turbocharged |
| Cylinders | 4 |
| Displacement | 4.43 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Stationary |
| Certifications | U.S. EPA Stationary, U.S. EPA Stationary Emergency |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Generac SG080?
The Generac SG080 is rated at 100 kVA standby / 91 kVA prime at 60 Hz (1,800 rpm).
Does the SG080 run at 50 Hz or 60 Hz?
The Generac SG080 is rated for 60 Hz (1,800 rpm).
What fuel does the Generac SG080 use?
The Generac SG080 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the SG080?
The Generac SG080 is an inline-4 (4-cylinder) engine with a displacement of 4.43 L.
What emissions standard does the SG080 meet?
The Generac SG080 is certified to U.S. EPA Stationary emissions standards.
Is the Generac SG080 still in production?
Yes — the Generac SG080 is a current production model.
Is a datasheet available for the SG080?
Yes — an official Generac datasheet for the Generac SG080 can be downloaded from this page.
