Guascor
Guascor G-24HM
G-HM
Guascor G-24HM — 24 L L8 spark-ignition gas engine (G-HM series), multi-fuel: natural gas, biogas, landfill/sewage gas, syngas, propane and wellhead/flare gas. 500 kWe at 1500 rpm / 50 Hz, 500 kWe at 1800 rpm / 60 Hz; low-emission (NOx < 1 g/bhp·hr).
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-08
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 625 kVA
- Electrical Output
- 500 kWe
- Cylinders
- L8
- Displacement
- 24 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 520 | 500 | 625 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 520 | 500 | 625 |
Ask about Guascor G-24HM
Choose parts / service or sourcing. Your message includes this model and page link.
Guascor G-24HM overhaul & repair parts
Already running a Guascor G-24HM? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with G-24HM and your selected categories included. Attach your photos there.
Guascor G-24HM generator set context
The Guascor G-24HM is listed here as a natural gas generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 625 kVA / 500 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Guascor |
| Model | G-24HM |
| Series | G-HM |
| Configuration | L8 |
| Cylinders | 8 |
| Displacement | 24 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Spain |
Frequently asked questions
What is the power output of the Guascor G-24HM?
The Guascor G-24HM is rated at 625 kVA prime at 50 Hz (1,500 rpm); and 625 kVA prime at 60 Hz (1,800 rpm).
Does the G-24HM run at 50 Hz or 60 Hz?
The Guascor G-24HM is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Guascor G-24HM use?
The Guascor G-24HM is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the G-24HM?
The Guascor G-24HM is an inline-8 (8-cylinder) engine with a displacement of 24 L.
What is the catalog status of the Guascor G-24HM?
The Guascor G-24HM is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the G-24HM?
This page links reference documents for the Guascor G-24HM. Check each document's title, model coverage, revision and rating conditions before using it for selection.
