Hino
Hino W04D
W Series
Hino W04D 4L 4-cylinder diesel engine for generator sets. ~32 kWe standby at 50Hz (representative rating). Unregulated. Turbocharged.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-06-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 40 kVA
- Electrical Output
- 32 kWe
- Cylinders
- L4
- Displacement
- 4 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 32 | 28.8 | 36 |
| Standby Power | 35.6 | 32 | 40 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 38.4 | 34.6 | 43.3 |
| Standby Power | 42.7 | 38.4 | 48 |
Ask about Hino W04D
Choose parts / service or sourcing. Your message includes this model and page link.
Hino W04D overhaul & repair parts
Already running a Hino W04D? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with W04D and your selected categories included. Attach your photos there.
Hino W04D generator set context
The Hino W04D is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 40 kVA / 32 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hino |
| Model | W04D |
| Series | W Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Hino W04D?
The Hino W04D is rated at 40 kVA standby / 36 kVA prime at 50 Hz (1,500 rpm); and 48 kVA standby / 43 kVA prime at 60 Hz (1,800 rpm).
Does the W04D run at 50 Hz or 60 Hz?
The Hino W04D is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hino W04D use?
The Hino W04D is a diesel generator-set engine.
What is the displacement and cylinder configuration of the W04D?
The Hino W04D is an inline-4 (4-cylinder) engine with a displacement of 4 L.
What is the catalog status of the Hino W04D?
The Hino W04D is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
