HND CHD314V8

HND CHD314V8 — V8 diesel engine. Find specifications, documents and parts support below.

View datasheet Ask about this engine

Production StatusProduction Discontinued

CHD314

Specifications and documentation remain archived for reference.

Mechanical Output: 350 kW
Cylinders: V8
Rated Speed: 1,500 / 1,800 RPM

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

Rating	Prime	Standby
Mechanical power kWm	335	350

60 Hz1800 RPM

Rating	Prime	Standby
Mechanical power kWm	370	390

Estimated electrical output

Engine power × 0.90. These are estimates, not manufacturer generator ratings. Actual output depends on the alternator and operating conditions.

Frequency / duty	Engine	Estimate
50 HzStandby	350 kWm	315 kWe
50 HzPrime	335 kWm	301.5 kWe
60 HzStandby	390 kWm	351 kWe
60 HzPrime	370 kWm	333 kWe

Datasheet & documents

Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.

Downloads

Brochure
HND selection brochure — CHD314V8 — PDF pp. 69–71
15.7 MB

Source notes

Industrial generating-set engine.

Bore/stroke 132/140 mm; 60-degree V.

Unit-cylinder displacement 1.92 L.

SFC 196/199 g/kWh at 1500/1800 rpm.

Weight excludes fan; approved drawings prevail.

Source: HND Power and Equipment Selection Brochure, manufacturer archive uploaded August 2022: hnd.com.cn · source PDF pages 69–71.

Ratings are engine mechanical kW; 1500/1800 rpm are stored as 50/60 Hz direct-coupled generator ratings.

Production status is unconfirmed.

Discontinued is the owner-approved catalogue classification for historical models with unknown production status, not a manufacturer-confirmed discontinuation.

View CHD314V8 spec image

HND CHD314V8 V8 diesel generator engine specifications — Shareable spec cardHND CHD314V8 summary imageOpen image

Technical specifications

Technical Specifications

Brand	HND
Model	CHD314V8
Series	CHD314
Configuration	V8
Cylinders	8
Compression Ratio	15:1
Dry Weight	1600 kg
Fuel Type	Diesel
Country of Origin	China

Check your engine model

The HND CHD314V8 is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 350 kW / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
