Hyundai
Hyundai DP054CAP
DP054 Series
Hyundai DP054CAP 5L 4-cylinder diesel engine for generator sets. EPA Tier 4 Final certified.
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP054CAP and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 139 kVA
- Electrical Output
- 111 kWe
- Cylinders
- L4
- Displacement
- 5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 112.2 | 101 | 126.3 |
| Standby Power | 123.3 | 111 | 138.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 131.1 | 118 | 147.5 |
| Standby Power | 145.6 | 131 | 163.8 |
Hyundai DP054CAP generator set context
The Hyundai DP054CAP is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 139 kVA / 111 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP054CAP |
| Series | DP054 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP054CAP?
The Hyundai DP054CAP is rated at 139 kVA standby / 126 kVA prime at 50 Hz (1,500 rpm); and 164 kVA standby / 148 kVA prime at 60 Hz (1,800 rpm).
Does the DP054CAP run at 50 Hz or 60 Hz?
The Hyundai DP054CAP is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP054CAP use?
The Hyundai DP054CAP is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP054CAP?
The Hyundai DP054CAP is an inline-4 (4-cylinder) engine with a displacement of 5 L.
What emissions standard does the DP054CAP meet?
The Hyundai DP054CAP is certified to U.S. EPA Final Tier 4 emissions standards.
Is the Hyundai DP054CAP still in production?
Yes — the Hyundai DP054CAP is a current production model.
Is a datasheet available for the DP054CAP?
Yes — an official Hyundai datasheet for the Hyundai DP054CAP can be downloaded from this page.
