Hyundai
Hyundai DP126CD
DP126 Series
Hyundai DP126CD 11.1L 6-cylinder diesel engine for generator sets. Unregulated (no emission certification).
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP126CD and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 469 kVA
- Electrical Output
- 375 kWe
- Cylinders
- L6
- Displacement
- 11.1 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 376.7 | 339 | 423.8 |
| Standby Power | 416.7 | 375 | 468.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 410 | 369 | 461.3 |
| Standby Power | 454.4 | 409 | 511.3 |
Hyundai DP126CD generator set context
The Hyundai DP126CD is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 469 kVA / 375 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP126CD |
| Series | DP126 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 11.1 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP126CD?
The Hyundai DP126CD is rated at 469 kVA standby / 424 kVA prime at 50 Hz (1,500 rpm); and 511 kVA standby / 461 kVA prime at 60 Hz (1,800 rpm).
Does the DP126CD run at 50 Hz or 60 Hz?
The Hyundai DP126CD is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP126CD use?
The Hyundai DP126CD is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP126CD?
The Hyundai DP126CD is an inline-6 (6-cylinder) engine with a displacement of 11.1 L.
Is the Hyundai DP126CD still in production?
Yes — the Hyundai DP126CD is a current production model.
Is a datasheet available for the DP126CD?
Yes — an official Hyundai datasheet for the Hyundai DP126CD can be downloaded from this page.
