Hyundai
Hyundai DP372CCS
DX37
Hyundai DP372CCS, DX37 common-rail generator-drive engine, 36.9 L V12. Updated from the user-supplied Hyundai / Power Solutions Limited lineup dated 2026-10-07. The sheet lists U.S. EPA Tier 2; this is a lineup declaration, not an independently checked model-year certification certificate. Mechanical engine kW and reference genset electrical kWe are stored separately. Ratings are rounded reference values; final ratings require the specific engine technical datasheet and genset output depends on alternator efficiency. Unlisted frequency ratings and unsupported kVA are left blank. Listed dry weight is 3500 kg; dimensions and weight are for the engine without radiator.
Overhaul & repair parts- Supporting documents
- 1 document
- Last updated
- 2026-10-09
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,438 kVA
- Electrical Output
- 1,150 kWe
- Cylinders
- V12
- Displacement
- 36.9 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1127 | 1043 | — |
| Standby Power | 1240 | 1150 | — |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1291 | 1181 | — |
| Standby Power | 1420 | 1304 | — |
Ask about Hyundai DP372CCS
Choose parts / service or sourcing. Your message includes this model and page link.
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamHyundai DP372CCS overhaul & repair parts
Already running a Hyundai DP372CCS? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with DP372CCS and your selected categories included. Attach your photos there.
Hyundai DP372CCS generator set context
The Hyundai DP372CCS is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,438 kVA / 1,150 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP372CCS |
| Series | DX37 |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 36.9 L |
| Dry Weight | 3500 kg |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Emissions Standard | U.S. EPA Tier 2 |
Frequently asked questions
What is the power output of the Hyundai DP372CCS?
The Hyundai DP372CCS is rated at 1,438 kVA standby / 1,304 kVA prime at 50 Hz (1,500 rpm); and 1,630 kVA standby / 1,476 kVA prime at 60 Hz (1,800 rpm).
Does the DP372CCS run at 50 Hz or 60 Hz?
The Hyundai DP372CCS is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP372CCS use?
The Hyundai DP372CCS is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP372CCS?
The Hyundai DP372CCS is a V12 (12-cylinder) engine with a displacement of 36.9 L.
What emissions information is listed for the DP372CCS?
This record lists U.S. EPA Tier 2 for the Hyundai DP372CCS. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Hyundai DP372CCS?
The Hyundai DP372CCS is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the DP372CCS?
This page links reference documents for the Hyundai DP372CCS. Check each document's title, model coverage, revision and rating conditions before using it for selection.
