Isuzu
6HK1X
6H-Series
Isuzu 6HK1X 7.79L 6-cylinder diesel engine for generator sets. 198 kW prime at 60Hz. Euro Stage IIIA / U.S. EPA Tier 3.
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 168 | 151.2 | 189 |
| Standby Power | 184.8 | 166.3 | 207.9 |
60 Hz2160 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 198 | 178.2 | 222.7 |
| Standby Power | 217.8 | 196 | 245 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | Isuzu |
| Model | 6HK1X |
| Series | 6H-Series |
| Configuration | Turbocharged, Intercooled |
| Cylinders | 6 |
| Displacement | 7.79 L |
| Fuel Type | Diesel |
| Emissions Standard | Euro Stage IIIA / U.S. EPA Tier 3 |
| Country of Origin | Japan |
