Isuzu
6WG1X
6W-Series
Isuzu 6WG1X 15.681L 6-cylinder diesel engine for generator sets. 382 kW prime at 60Hz. U.S. EPA Final Tier 4.
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 353 | 317.7 | 397.1 |
| Standby Power | 388.3 | 349.5 | 436.9 |
60 Hz2160 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 382 | 343.8 | 429.8 |
| Standby Power | 420.2 | 378.2 | 472.7 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | Isuzu |
| Model | 6WG1X |
| Series | 6W-Series |
| Configuration | Turbocharged, Intercooled |
| Cylinders | 6 |
| Displacement | 15.681 L |
| Fuel Type | Diesel |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | Japan |
