JCB
JCB 448 TA3-75
448 Dieselmax
JCB 448 Dieselmax 4.8L 4-cylinder diesel engine for generator sets. 70 kW prime / 75 kW standby at 60Hz. U.S. EPA Tier 3. Turbocharged, Intercooled, Common Rail.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-28
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 73 kVA
- Electrical Output
- 59 kWe
- Cylinders
- L4
- Displacement
- 4.8 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 60 | 54 | 67.5 |
| Standby Power | 65 | 58.5 | 73.1 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 70 | 63 | 78.8 |
| Standby Power | 75 | 67.5 | 84.4 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about JCB 448 TA3-75
Choose parts / service or sourcing. Your message includes this model and page link.
JCB 448 TA3-75 overhaul & repair parts
Already running a JCB 448 TA3-75? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 448 TA3-75 and your selected categories included. Attach your photos there.
JCB 448 TA3-75 generator set context
The JCB 448 TA3-75 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 73 kVA / 59 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | JCB |
| Model | 448 TA3-75 |
| Series | 448 Dieselmax |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 4.8 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 3 |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the JCB 448 TA3-75?
The JCB 448 TA3-75 is rated at 73 kVA standby / 68 kVA prime at 50 Hz (1,500 rpm); and 84 kVA standby / 79 kVA prime at 60 Hz (1,800 rpm).
Does the 448 TA3-75 run at 50 Hz or 60 Hz?
The JCB 448 TA3-75 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the JCB 448 TA3-75 use?
The JCB 448 TA3-75 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 448 TA3-75?
The JCB 448 TA3-75 is an inline-4 (4-cylinder) engine with a displacement of 4.8 L.
What emissions information is listed for the 448 TA3-75?
This record lists U.S. EPA Tier 3 for the JCB 448 TA3-75. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the JCB 448 TA3-75?
The JCB 448 TA3-75 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 448 TA3-75?
This page links reference documents for the JCB 448 TA3-75. Check each document's title, model coverage, revision and rating conditions before using it for selection.
