Jichai
Jichai 12V190ZDT1-2
190 series
Jichai 12V190ZDT1-2 — 71.4 L V12 (190 × 210 mm) spark-ignited natural gas generator engine (CNPC Jichai G12V190 first-generation external-mix series, genset 550GF-TK). 600 kW engine / 550 kWe at 1000 rpm; single-point injection with post-turbo membrane mixing, NOx ≤1200 mg/Nm³@5%O₂.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-06-10
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 688 kVA
- Electrical Output
- 550 kWe
- Cylinders
- V12
- Displacement
- 71.4 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 550 | 687.5 |
Ask about Jichai 12V190ZDT1-2
Choose parts / service or sourcing. Your message includes this model and page link.
Jichai 12V190ZDT1-2 overhaul & repair parts
Already running a Jichai 12V190ZDT1-2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 12V190ZDT1-2 and your selected categories included. Attach your photos there.
Jichai 12V190ZDT1-2 generator set context
The Jichai 12V190ZDT1-2 is listed here as a natural gas generator-drive engine for 50 Hz generator sets, with a headline 688 kVA / 550 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | 12V190ZDT1-2 |
| Series | 190 series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 71.4 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai 12V190ZDT1-2?
The Jichai 12V190ZDT1-2 is rated at 688 kVA prime at 50 Hz (1,000 rpm).
Does the 12V190ZDT1-2 run at 50 Hz or 60 Hz?
The Jichai 12V190ZDT1-2 is rated for 50 Hz (1,000 rpm).
What fuel does the Jichai 12V190ZDT1-2 use?
The Jichai 12V190ZDT1-2 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the 12V190ZDT1-2?
The Jichai 12V190ZDT1-2 is a V12 (12-cylinder) engine with a displacement of 71.4 L.
What is the catalog status of the Jichai 12V190ZDT1-2?
The Jichai 12V190ZDT1-2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
