Jichai
Jichai L16V200ZLWd-2
200 series
Jichai L16V200ZLWd-2 — 128.2 L V16 (200 × 255 mm) spark-ignited gas generator engine (CNPC Jichai L16V200 series, genset 1500GF20-Wd). 1760 kW engine / 1500 kWe at 1000 rpm, 10.5 kV; BMEP 1.648 MPa, thermal efficiency >40%; runs coal-mine gas (瓦斯/CBM).
- Prime Power · 50 Hz
- 1,875 kVA
- Electrical Output
- 1,500 kWe
- Cylinders
- V16
- Displacement
- 128.2 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1500 | 1875 |
Jichai L16V200ZLWd-2 generator set context
The Jichai L16V200ZLWd-2 is listed here as a coal gas generator-drive engine for 50 Hz generator sets, with a headline 1,875 kVA / 1,500 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | L16V200ZLWd-2 |
| Series | 200 series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 128.2 L |
| Fuel Type | Coal Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai L16V200ZLWd-2?
The Jichai L16V200ZLWd-2 is rated at 1,875 kVA prime at 50 Hz (1,000 rpm).
Does the L16V200ZLWd-2 run at 50 Hz or 60 Hz?
The Jichai L16V200ZLWd-2 is rated for 50 Hz (1,000 rpm).
What fuel does the Jichai L16V200ZLWd-2 use?
The Jichai L16V200ZLWd-2 is a Coal Gas generator-set engine.
What is the displacement and cylinder configuration of the L16V200ZLWd-2?
The Jichai L16V200ZLWd-2 is a V16 (16-cylinder) engine with a displacement of 128.2 L.
Is the Jichai L16V200ZLWd-2 still in production?
Yes — the Jichai L16V200ZLWd-2 is a current production model.
