John Deere
John Deere 6090HFG06
6090 Series
The John Deere 6090HFG06 is a 9-litre inline-6 diesel engine for generator sets, rated at 328 kVA / 262 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in United States. It meets U.S. EPA Final Tier 4 emissions standards.
Get help with this engine
Tell Haifeng whether you already own a John Deere 6090HFG06 engine/generator or need to source this model for a project.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 328 kVA
- Electrical Output
- 262 kWe
- Cylinders
- L6
- Displacement
- 9 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 263.3 | 237 | 296.3 |
| Standby Power | 291.1 | 262 | 327.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 286.7 | 258 | 322.5 |
| Standby Power | 316.7 | 285 | 356.3 |
John Deere 6090HFG06 generator set context
The John Deere 6090HFG06 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 328 kVA / 262 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | John Deere |
| Model | 6090HFG06 |
| Series | 6090 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 9 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the John Deere 6090HFG06?
The John Deere 6090HFG06 is rated at 328 kVA standby / 296 kVA prime at 50 Hz (1,500 rpm); and 356 kVA standby / 323 kVA prime at 60 Hz (1,800 rpm).
Does the 6090HFG06 run at 50 Hz or 60 Hz?
The John Deere 6090HFG06 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the John Deere 6090HFG06 use?
The John Deere 6090HFG06 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 6090HFG06?
The John Deere 6090HFG06 is an inline-6 (6-cylinder) engine with a displacement of 9 L.
What emissions standard does the 6090HFG06 meet?
The John Deere 6090HFG06 is certified to U.S. EPA Final Tier 4 emissions standards.
Is the John Deere 6090HFG06 still in production?
Yes — the John Deere 6090HFG06 is a current production model.
Is a datasheet available for the 6090HFG06?
Yes — an official John Deere datasheet for the John Deere 6090HFG06 can be downloaded from this page.
