Kohler KD36V16
Kohler KD36V16 36L 16-cylinder G-Drive diesel engine for generator sets (KD1250–KD1500). 1350 ekW standby at 60Hz / 1500 ekW standby at 50Hz. EPA Tier 2. Turbocharged Aftercooled, Common Rail.
Production StatusIn Production
KD Series
- Configuration
- V16
- Displacement
- 36 L
- Fuel
- Diesel
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| Rating | Prime | Standby |
|---|---|---|
| Mechanical power kWm | 1,511.1 | 1,666.7 |
| Electrical output kWe | 1,360 | 1,500 |
| Apparent power kVA | 1,700 | 1,875 |
60 Hz1800 RPM
| Rating | Prime | Standby |
|---|---|---|
| Mechanical power kWm | 1,361.1 | 1,500 |
| Electrical output kWe | 1,225 | 1,350 |
| Apparent power kVA | 1,531.3 | 1,687.5 |
Datasheet & documents
Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.
Technical specifications
Technical Specifications
| Brand | Kohler |
| Model | KD36V16 |
| Series | KD Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 36 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | France |
Check your engine model
The Kohler KD36V16 is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 1,875 kVA / 1,500 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
Other ways this model is written
kd36v16Kohler KD36V16KD Series KD36V16
KD36V16 repair parts
Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.
Get a parts & air-shipping quoteIn-stock parts: same-day dispatch
Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.
Find the right part
Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.
Other parts? Add them in the chat.
Get my parts quote on WhatsAppWe’ll confirm the correct parts, stock and delivery cost before you order.
Opens WhatsApp. Attach photos in the chat.
Photos and details to send
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Part-number references
Confirm fitment against your engine serial number.
- Piston230610224
Fitment details & source
Piston cpl.
Fitment check: The archived source and independent QA bind complete model KD36V16 and printed part number 230610224 in the cited bounded record. Private evidence only. Source quantity was not staged; confirm engine serial/build and current OEM applicability before use.
Source: Kohler KD36V16 Service Parts, TP-7054
Get help with this engine
Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.
Other ways to contact us
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamNeed help after checking the documents?
Send us the part number or describe the problem. This engine model is included in your message.
Send this model enquiry by emailOr browse Haifeng's diesel generator sets
Frequently asked questions
What is the power output of the Kohler KD36V16?
The Kohler KD36V16 is rated at 1,875 kVA standby / 1,700 kVA prime at 50 Hz (1,500 rpm); and 1,688 kVA standby / 1,531 kVA prime at 60 Hz (1,800 rpm).
Does the KD36V16 run at 50 Hz or 60 Hz?
The Kohler KD36V16 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Kohler KD36V16 use?
The Kohler KD36V16 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the KD36V16?
The Kohler KD36V16 is a V16 (16-cylinder) engine with a displacement of 36 L.
What emissions information is listed for the KD36V16?
This record lists U.S. EPA Tier 2 for the Kohler KD36V16. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Kohler KD36V16?
The Kohler KD36V16 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the KD36V16?
This page links reference documents for the Kohler KD36V16. Check each document's title, model coverage, revision and rating conditions before using it for selection.
