Kohler
Kohler KDI2504TCR
KDI Series
Kohler KDI2504TCR 2.5L 4-cylinder common-rail diesel engine for compact generator sets. 30 kWe standby at 60Hz. EPA Tier 4 Final. Kohler's small-diesel (Lombardini) line, distinct from the large KD Series. Turbocharged, Common Rail.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 33 kVA
- Electrical Output
- 26 kWe
- Cylinders
- L4
- Displacement
- 2.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 26.7 | 24 | 30 |
| Standby Power | 28.9 | 26 | 32.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 30 | 27 | 33.8 |
| Standby Power | 33.3 | 30 | 37.5 |
Ask about Kohler KDI2504TCR
Choose parts / service or sourcing. Your message includes this model and page link.
Kohler KDI2504TCR overhaul & repair parts
Already running a Kohler KDI2504TCR? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with KDI2504TCR and your selected categories included. Attach your photos there.
Kohler KDI2504TCR generator set context
The Kohler KDI2504TCR is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 33 kVA / 26 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Kohler |
| Model | KDI2504TCR |
| Series | KDI Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 2.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | Italy |
Frequently asked questions
What is the power output of the Kohler KDI2504TCR?
The Kohler KDI2504TCR is rated at 33 kVA standby / 30 kVA prime at 50 Hz (1,500 rpm); and 38 kVA standby / 34 kVA prime at 60 Hz (1,800 rpm).
Does the KDI2504TCR run at 50 Hz or 60 Hz?
The Kohler KDI2504TCR is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Kohler KDI2504TCR use?
The Kohler KDI2504TCR is a diesel generator-set engine.
What is the displacement and cylinder configuration of the KDI2504TCR?
The Kohler KDI2504TCR is an inline-4 (4-cylinder) engine with a displacement of 2.5 L.
What emissions information is listed for the KDI2504TCR?
This record lists U.S. EPA Final Tier 4 for the Kohler KDI2504TCR. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Kohler KDI2504TCR?
The Kohler KDI2504TCR is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the KDI2504TCR?
This page links reference documents for the Kohler KDI2504TCR. Check each document's title, model coverage, revision and rating conditions before using it for selection.
