Kubota
Kubota D1105-E2BG-CHN-1
D Series
The Kubota D1105-E2BG-CHN-1 is a 1.105-litre inline-3 diesel engine for generator sets, rated at 11 kVA / 9 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in Japan.
Get help with this engine
Tell Haifeng whether you already own a Kubota D1105-E2BG-CHN-1 engine/generator or need to source this model for a project.
- Manufacturer files
- No datasheet
- Last updated
- 2026-07-01
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 11 kVA
- Electrical Output
- 9 kWe
- Cylinders
- L3
- Displacement
- 1.105 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 8.9 | 8 | 10 |
| Standby Power | 10 | 9 | 11.3 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 10 | 9 | 11.3 |
| Standby Power | 12.2 | 11 | 13.8 |
Kubota D1105-E2BG-CHN-1 generator set context
The Kubota D1105-E2BG-CHN-1 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 11 kVA / 9 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Kubota |
| Model | D1105-E2BG-CHN-1 |
| Series | D Series |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 1.105 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Kubota D1105-E2BG-CHN-1?
The Kubota D1105-E2BG-CHN-1 is rated at 11 kVA standby / 10 kVA prime at 50 Hz (1,500 rpm); and 14 kVA standby / 11 kVA prime at 60 Hz (1,800 rpm).
Does the D1105-E2BG-CHN-1 run at 50 Hz or 60 Hz?
The Kubota D1105-E2BG-CHN-1 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Kubota D1105-E2BG-CHN-1 use?
The Kubota D1105-E2BG-CHN-1 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the D1105-E2BG-CHN-1?
The Kubota D1105-E2BG-CHN-1 is an inline-3 (3-cylinder) engine with a displacement of 1.105 L.
Is the Kubota D1105-E2BG-CHN-1 still in production?
Yes — the Kubota D1105-E2BG-CHN-1 is a current production model.
