Kubota
Kubota D1005-E4BG1-SAE-2
D Series
Kubota D1005-E4BG1-SAE-2 1.001 L L3 diesel engine for generator sets. Kubota publishes 8.7 kWm continuous and 9.8 kWm standby at 1800 RPM. Euro Stage V / U.S. EPA Final Tier 4.
Overhaul & repair parts- Supporting documents
- 2 documents · 1 datasheet
- Last updated
- 2026-07-25
- Package route
- diesel generator sets
- Mechanical Output
- 10 kW
- Cylinders
- L3
- Displacement
- 1.001 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 8.7 | — | — |
| Standby Power | 9.8 | — | — |
Ask about Kubota D1005-E4BG1-SAE-2
Choose parts / service or sourcing. Your message includes this model and page link.
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamKubota D1005-E4BG1-SAE-2 overhaul & repair parts
Already running a Kubota D1005-E4BG1-SAE-2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with D1005-E4BG1-SAE-2 and your selected categories included. Attach your photos there.
Kubota D1005-E4BG1-SAE-2 generator set context
The Kubota D1005-E4BG1-SAE-2 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 10 kW / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Kubota |
| Model | D1005-E4BG1-SAE-2 |
| Series | D Series |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 1.001 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V / U.S. EPA Final Tier 4 |
| Certifications | Euro Stage V, U.S. EPA Final Tier 4 |
| Country of Origin | Japan |
Frequently asked questions
Does the D1005-E4BG1-SAE-2 run at 50 Hz or 60 Hz?
The Kubota D1005-E4BG1-SAE-2 is rated for 60 Hz (1,800 rpm).
What fuel does the Kubota D1005-E4BG1-SAE-2 use?
The Kubota D1005-E4BG1-SAE-2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the D1005-E4BG1-SAE-2?
The Kubota D1005-E4BG1-SAE-2 is an inline-3 (3-cylinder) engine with a displacement of 1.001 L.
What emissions information is listed for the D1005-E4BG1-SAE-2?
This record lists Euro Stage V / U.S. EPA Final Tier 4 for the Kubota D1005-E4BG1-SAE-2. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Kubota D1005-E4BG1-SAE-2?
The Kubota D1005-E4BG1-SAE-2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the D1005-E4BG1-SAE-2?
This page links reference documents for the Kubota D1005-E4BG1-SAE-2. Check each document's title, model coverage, revision and rating conditions before using it for selection.
