Liebherr
D9508
D95/96 V-Series
Liebherr D9508 16.2L 8-cylinder diesel engine for generator sets. 550 kWm standby at 1500rpm. Euro Stage V. kWe estimated at 96% alternator efficiency.
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 495 | 475.2 | 594 |
| Standby Power | 550 | 528 | 660 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | Liebherr |
| Model | D9508 |
| Series | D95/96 V-Series |
| Configuration | V8, Turbocharged Intercooled |
| Cylinders | 8 |
| Displacement | 16.2 L |
| Fuel Type | Diesel |
| Emissions Standard | Euro Stage V |
| Country of Origin | Switzerland |
