Lister Petter
Lister Petter LP1686EG1
Earth Max Electronic
Lister Petter LP1686EG1 earth max electronic diesel generator-drive engine. 50 Hz 1800 kWe prime / 2000 kWe standby. Euro Stage III emissions.
Chat on WhatsApp about this engine
Opens WhatsApp with Lister Petter LP1686EG1 and this page link filled in.
- Manufacturer files
- No datasheet
- Last updated
- 2026-07-24
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,500 kVA
- Electrical Output
- 2,000 kWe
- Cylinders
- V16
- Displacement
- 86.02 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1922 | 1800 | 2250 |
| Standby Power | 2142 | 2000 | 2500 |
Lister Petter LP1686EG1 generator set context
The Lister Petter LP1686EG1 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,500 kVA / 2,000 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Lister Petter |
| Model | LP1686EG1 |
| Series | Earth Max Electronic |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 86.02 L |
| Compression Ratio | 15:1 |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage III |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the Lister Petter LP1686EG1?
The Lister Petter LP1686EG1 is rated at 2,500 kVA standby / 2,250 kVA prime at 50 Hz (1,500 rpm).
Does the LP1686EG1 run at 50 Hz or 60 Hz?
The Lister Petter LP1686EG1 is rated for 50 Hz (1,500 rpm).
What fuel does the Lister Petter LP1686EG1 use?
The Lister Petter LP1686EG1 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the LP1686EG1?
The Lister Petter LP1686EG1 is a V16 (16-cylinder) engine with a displacement of 86.02 L.
What emissions standard does the LP1686EG1 meet?
The Lister Petter LP1686EG1 is certified to Euro Stage III emissions standards.
Is the Lister Petter LP1686EG1 still in production?
Yes — the Lister Petter LP1686EG1 is a current production model.
