Lister Petter
Lister Petter LP322EVG2
ECU Electronic
Lister Petter LP322EVG2 ecu electronic diesel generator-drive engine. 50 Hz 32 kWe prime / 35 kWe standby; 60 Hz 40 kWe prime / 44 kWe standby. Euro Stage V emissions. Dual-frequency.
Chat on WhatsApp about this engine
Opens WhatsApp with Lister Petter LP322EVG2 and this page link filled in.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-07-24
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 44 kVA
- Electrical Output
- 35 kWe
- Cylinders
- L3
- Displacement
- 2.2 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 37.5 | 32 | 40 |
| Standby Power | 41.5 | 35 | 44 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 46.5 | 40 | 50 |
| Standby Power | 51.5 | 44 | 55 |
Lister Petter LP322EVG2 generator set context
The Lister Petter LP322EVG2 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 44 kVA / 35 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Lister Petter |
| Model | LP322EVG2 |
| Series | ECU Electronic |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 2.2 L |
| Compression Ratio | 17.5:1 |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the Lister Petter LP322EVG2?
The Lister Petter LP322EVG2 is rated at 44 kVA standby / 40 kVA prime at 50 Hz (1,500 rpm); and 55 kVA standby / 50 kVA prime at 60 Hz (1,800 rpm).
Does the LP322EVG2 run at 50 Hz or 60 Hz?
The Lister Petter LP322EVG2 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Lister Petter LP322EVG2 use?
The Lister Petter LP322EVG2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the LP322EVG2?
The Lister Petter LP322EVG2 is an inline-3 (3-cylinder) engine with a displacement of 2.2 L.
What emissions standard does the LP322EVG2 meet?
The Lister Petter LP322EVG2 is certified to Euro Stage V emissions standards.
Is the Lister Petter LP322EVG2 still in production?
Yes — the Lister Petter LP322EVG2 is a current production model.
Is a datasheet available for the LP322EVG2?
Yes — an official Lister Petter datasheet for the Lister Petter LP322EVG2 can be downloaded from this page.
