MAN
MAN E 0834 E302
E0834
MAN E 0834 E302 — 4.6 L L4 (108 mm bore) spark-ignition natural-gas engine, stoichiometric (λ=1, 3-way catalyst). Mechanical output 54 kW at 1500 rpm / 50 Hz, 62 kW at 1800 rpm / 60 Hz (electrical ~52 kWe); for power generation / CHP.
- Prime Power · 50 Hz
- 65 kVA
- Electrical Output
- 52 kWe
- Cylinders
- L4
- Displacement
- 4.6 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 54 | 52 | 65 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 62 | 60 | 75 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
MAN E 0834 E302 generator set context
The MAN E 0834 E302 is listed here as a natural gas generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 65 kVA / 52 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | MAN |
| Model | E 0834 E302 |
| Series | E0834 |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 4.6 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the MAN E 0834 E302?
The MAN E 0834 E302 is rated at 65 kVA prime at 50 Hz (1,500 rpm); and 75 kVA prime at 60 Hz (1,800 rpm).
Does the E 0834 E302 run at 50 Hz or 60 Hz?
The MAN E 0834 E302 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the MAN E 0834 E302 use?
The MAN E 0834 E302 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the E 0834 E302?
The MAN E 0834 E302 is an inline-4 (4-cylinder) engine with a displacement of 4.6 L.
Is the MAN E 0834 E302 still in production?
Yes — the MAN E 0834 E302 is a current production model.
Is a datasheet available for the E 0834 E302?
Yes — an official MAN datasheet for the MAN E 0834 E302 can be downloaded from this page.
