MAN
MAN E 3872 LE202
E3872
MAN E 3872 LE202 — 29.6 L V12 (138 mm bore) spark-ignition natural-gas engine, lean-burn. Mechanical output 840 kW at 1800 rpm / 60 Hz (electrical ~806 kWe); for power generation / CHP.
- Prime Power · 60 Hz
- 1,008 kVA
- Electrical Output
- 806 kWe
- Cylinders
- V12
- Displacement
- 29.6 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 840 | 806 | 1007.5 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | MAN |
| Model | E 3872 LE202 |
| Series | E3872 |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 29.6 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
