Mitsubishi
Mitsubishi GS16R-PTK
GSR
Mitsubishi GS16R-PTK is a 65.37 L V16 Miller-cycle lean-burn gas engine for generator and cogeneration service. MHI publishes a 930 kWe, 1500 RPM base configuration. Rudox packaged the engine as the ERM1000GS, rated 1000 kWe standby at 60 Hz and 1800 RPM. EPA lineage FRDXB65.5MGS records the matching 65.5 L V16 stationary configuration; the workbook's 49.1 L displacement entry is a source-field error.
Overhaul & repair parts- Manufacturer files
- 3 datasheets
- Last updated
- 2026-07-25
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 1,163 kVA
- Electrical Output
- 930 kWe
- Cylinders
- V16
- Displacement
- 65.37 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 930 | 1162.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | — | 1000 | 1250 |
Ask about Mitsubishi GS16R-PTK
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi GS16R-PTK overhaul & repair parts
Already running a Mitsubishi GS16R-PTK? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with GS16R-PTK and your selected categories included. Attach your photos there.
Mitsubishi GS16R-PTK generator set context
The Mitsubishi GS16R-PTK is listed here as a natural gas generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,163 kVA / 930 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | GS16R-PTK |
| Series | GSR |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 65.37 L |
| Dry Weight | 6770 kg |
| Dimensions (L×W×H) | 2876 × 1820 × 2137 mm |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Stationary |
| Certifications | U.S. EPA Stationary, U.S. EPA NSPS Subpart JJJJ, UL 2200 Available |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi GS16R-PTK?
The Mitsubishi GS16R-PTK is rated at 1,163 kVA prime at 50 Hz (1,500 rpm); and 1,250 kVA standby at 60 Hz (1,800 rpm).
Does the GS16R-PTK run at 50 Hz or 60 Hz?
The Mitsubishi GS16R-PTK is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Mitsubishi GS16R-PTK use?
The Mitsubishi GS16R-PTK is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the GS16R-PTK?
The Mitsubishi GS16R-PTK is a V16 (16-cylinder) engine with a displacement of 65.37 L.
What emissions information is listed for the GS16R-PTK?
This record lists U.S. EPA Stationary for the Mitsubishi GS16R-PTK. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Mitsubishi GS16R-PTK?
The Mitsubishi GS16R-PTK is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the GS16R-PTK?
This page links reference documents for the Mitsubishi GS16R-PTK. Check each document's title, model coverage, revision and rating conditions before using it for selection.
