Mitsubishi GS16R2-PTK-C
The Mitsubishi GS16R2-PTK-C is a 79.9-litre V16 natural gas engine for generator sets, rated at 1,875 kVA / 1,500 kWe prime power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in Japan.
- Prime Power · 50 Hz
- 1,875 kVA
- Electrical Output
- 1,500 kWe
- Cylinders
- V16
- Displacement
- 79.9 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1562.5 | 1500 | 1875 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | Mitsubishi |
| Model | GS16R2-PTK-C |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 79.9 L |
| Compression Ratio | 12.0:1 |
| Dry Weight | 8105 kg |
| Dimensions (L×W×H) | 3118 × 1479 × 2030 mm |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
