Mitsubishi
Mitsubishi L2E-Z562SDH
L2E Series
Mitsubishi L2E-Z562SDH 0.635L L2 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: prime 8.3 kWm at 2970 rpm, standby 9.7 kWm at 2970 rpm. Emissions: Euro Stage V.
- Standby Power · 50 Hz
- 10 kVA
- Electrical Output
- 8 kWe
- Cylinders
- L2
- Displacement
- 0.635 L
- Rated Speed
- 2,970 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz2970 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 8.3 | 7 | 8.8 |
| Standby Power | 9.7 | 8.2 | 10.3 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Mitsubishi L2E-Z562SDH generator set context
The Mitsubishi L2E-Z562SDH is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 10 kVA / 8 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | L2E-Z562SDH |
| Series | L2E Series |
| Configuration | L2 |
| Cylinders | 2 |
| Displacement | 0.635 L |
| Dry Weight | 91 kg |
| Dimensions (L×W×H) | 419 × 418 × 500 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi L2E-Z562SDH?
The Mitsubishi L2E-Z562SDH is rated at 10 kVA standby / 9 kVA prime at 50 Hz (2,970 rpm).
Does the L2E-Z562SDH run at 50 Hz or 60 Hz?
The Mitsubishi L2E-Z562SDH is rated for 50 Hz (2,970 rpm).
What fuel does the Mitsubishi L2E-Z562SDH use?
The Mitsubishi L2E-Z562SDH is a diesel generator-set engine.
What is the displacement and cylinder configuration of the L2E-Z562SDH?
The Mitsubishi L2E-Z562SDH is an inline-2 (2-cylinder) engine with a displacement of 0.635 L.
What emissions standard does the L2E-Z562SDH meet?
The Mitsubishi L2E-Z562SDH is certified to Euro Stage V emissions standards.
Is the Mitsubishi L2E-Z562SDH still in production?
Yes — the Mitsubishi L2E-Z562SDH is a current production model.
Is a datasheet available for the L2E-Z562SDH?
Yes — an official Mitsubishi datasheet for the Mitsubishi L2E-Z562SDH can be downloaded from this page.
Related Engines
Compare Mitsubishi L2E-Z562SDH
Reference
- Canonical page
- /engines/mitsubishi-l2e-z562sdh
- Last database update
- 2026-07-23
- Manufacturer files
- 1 datasheet linked
