Mitsubishi
Mitsubishi L3E-61SD-NP2
L3E Series
Mitsubishi L3E-61SD-NP2 0.952L L3 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: standby 7.3 kWm at 1485 rpm, prime 6.2 kWm at 1485 rpm. Emissions: Unregulated.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 8 kVA
- Electrical Output
- 6 kWe
- Cylinders
- L3
- Displacement
- 0.952 L
- Rated Speed
- 1,485 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1485 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 6.2 | 5.3 | 6.6 |
| Standby Power | 7.3 | 6.2 | 7.8 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi L3E-61SD-NP2
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi L3E-61SD-NP2 overhaul & repair parts
Already running a Mitsubishi L3E-61SD-NP2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with L3E-61SD-NP2 and your selected categories included. Attach your photos there.
Mitsubishi L3E-61SD-NP2 generator set context
The Mitsubishi L3E-61SD-NP2 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 8 kVA / 6 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | L3E-61SD-NP2 |
| Series | L3E Series |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 0.952 L |
| Dry Weight | 90 kg |
| Dimensions (L×W×H) | 556 × 418 × 532 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi L3E-61SD-NP2?
The Mitsubishi L3E-61SD-NP2 is rated at 8 kVA standby / 7 kVA prime at 50 Hz (1,485 rpm).
Does the L3E-61SD-NP2 run at 50 Hz or 60 Hz?
The Mitsubishi L3E-61SD-NP2 is rated for 50 Hz (1,485 rpm).
What fuel does the Mitsubishi L3E-61SD-NP2 use?
The Mitsubishi L3E-61SD-NP2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the L3E-61SD-NP2?
The Mitsubishi L3E-61SD-NP2 is an inline-3 (3-cylinder) engine with a displacement of 0.952 L.
What is the catalog status of the Mitsubishi L3E-61SD-NP2?
The Mitsubishi L3E-61SD-NP2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the L3E-61SD-NP2?
This page links reference documents for the Mitsubishi L3E-61SD-NP2. Check each document's title, model coverage, revision and rating conditions before using it for selection.
