Mitsubishi
Mitsubishi S12A2-PTA2
S12A2 Series
Mitsubishi S12A2-PTA2 33.930L V12 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: prime 764 kWm at 1500 rpm, standby 840 kWm at 1500 rpm; 60 Hz: prime 864 kWm at 1800 rpm, standby 950 kWm at 1800 rpm. Emissions: Unregulated.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 998 kVA
- Electrical Output
- 798 kWe
- Cylinders
- V12
- Displacement
- 33.93 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 764 | 725.6 | 907 |
| Standby Power | 840 | 798.4 | 998 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 864 | 820.8 | 1026 |
| Standby Power | 950 | 902.4 | 1128 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S12A2-PTA2
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S12A2-PTA2 overhaul & repair parts
Already running a Mitsubishi S12A2-PTA2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S12A2-PTA2 and your selected categories included. Attach your photos there.
Mitsubishi S12A2-PTA2 generator set context
The Mitsubishi S12A2-PTA2 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 998 kVA / 798 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S12A2-PTA2 |
| Series | S12A2 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 33.93 L |
| Dry Weight | 3400 kg |
| Dimensions (L×W×H) | 2163 × 1504 × 1542 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi S12A2-PTA2?
The Mitsubishi S12A2-PTA2 is rated at 998 kVA standby / 907 kVA prime at 50 Hz (1,500 rpm); and 1,128 kVA standby / 1,026 kVA prime at 60 Hz (1,800 rpm).
Does the S12A2-PTA2 run at 50 Hz or 60 Hz?
The Mitsubishi S12A2-PTA2 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Mitsubishi S12A2-PTA2 use?
The Mitsubishi S12A2-PTA2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S12A2-PTA2?
The Mitsubishi S12A2-PTA2 is a V12 (12-cylinder) engine with a displacement of 33.93 L.
What is the catalog status of the Mitsubishi S12A2-PTA2?
The Mitsubishi S12A2-PTA2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S12A2-PTA2?
This page links reference documents for the Mitsubishi S12A2-PTA2. Check each document's title, model coverage, revision and rating conditions before using it for selection.
