Mitsubishi
Mitsubishi S12R-PTA-C
S12R Series
Mitsubishi S12R-PTA-C 49.03L 12-cylinder Shanghai MHI generator-drive diesel engine. 1080 kWm prime and 1190 kWm standby at 50 Hz/1500 rpm.
Overhaul & repair parts- Supporting documents
- No documents linked
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,413 kVA
- Electrical Output
- 1,131 kWe
- Cylinders
- V12
- Displacement
- 49.03 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1080 | 1026 | 1282.5 |
| Standby Power | 1190 | 1130.5 | 1413.1 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S12R-PTA-C
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S12R-PTA-C overhaul & repair parts
Already running a Mitsubishi S12R-PTA-C? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S12R-PTA-C and your selected categories included. Attach your photos there.
Mitsubishi S12R-PTA-C generator set context
The Mitsubishi S12R-PTA-C is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 1,413 kVA / 1,131 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S12R-PTA-C |
| Series | S12R Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 49.03 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Mitsubishi S12R-PTA-C?
The Mitsubishi S12R-PTA-C is rated at 1,413 kVA standby / 1,283 kVA prime at 50 Hz (1,500 rpm).
Does the S12R-PTA-C run at 50 Hz or 60 Hz?
The Mitsubishi S12R-PTA-C is rated for 50 Hz (1,500 rpm).
What fuel does the Mitsubishi S12R-PTA-C use?
The Mitsubishi S12R-PTA-C is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S12R-PTA-C?
The Mitsubishi S12R-PTA-C is a V12 (12-cylinder) engine with a displacement of 49.03 L.
What is the catalog status of the Mitsubishi S12R-PTA-C?
The Mitsubishi S12R-PTA-C is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
