Mitsubishi
Mitsubishi S12U-PTA
S12U Series
Mitsubishi S12U-PTA 141.150L V12 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: prime 2429 kWm at 1000 rpm, standby 2518 kWm at 1000 rpm; 60 Hz: standby 2255 kWm at 900 rpm, prime 2182 kWm at 900 rpm, standby 2703 kWm at 1200 rpm, prime 2576 kWm at 1200 rpm. Emissions: Unregulated.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,990 kVA
- Electrical Output
- 2,392 kWe
- Cylinders
- V12
- Displacement
- 141.15 L
- Rated Speed
- 900 / 1,080 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz900 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2429 | 2308 | 2885 |
| Standby Power | 2518 | 2392 | 2990 |
60 Hz1080 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2576 | 2447.2 | 3059 |
| Standby Power | 2703 | 2568 | 3210 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S12U-PTA
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S12U-PTA overhaul & repair parts
Already running a Mitsubishi S12U-PTA? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S12U-PTA and your selected categories included. Attach your photos there.
Mitsubishi S12U-PTA generator set context
The Mitsubishi S12U-PTA is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 2,990 kVA / 2,392 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S12U-PTA |
| Series | S12U Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 141.15 L |
| Dry Weight | 15500 kg |
| Dimensions (L×W×H) | 3519 × 1820 × 2374 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi S12U-PTA?
The Mitsubishi S12U-PTA is rated at 2,990 kVA standby / 2,885 kVA prime at 50 Hz (900 rpm); and 3,210 kVA standby / 3,059 kVA prime at 60 Hz (1,080 rpm).
Does the S12U-PTA run at 50 Hz or 60 Hz?
The Mitsubishi S12U-PTA is available for both 50 Hz (900 rpm) and 60 Hz (1,080 rpm).
What fuel does the Mitsubishi S12U-PTA use?
The Mitsubishi S12U-PTA is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S12U-PTA?
The Mitsubishi S12U-PTA is a V12 (12-cylinder) engine with a displacement of 141.15 L.
What is the catalog status of the Mitsubishi S12U-PTA?
The Mitsubishi S12U-PTA is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S12U-PTA?
This page links reference documents for the Mitsubishi S12U-PTA. Check each document's title, model coverage, revision and rating conditions before using it for selection.
