Mitsubishi S16R-A2PTAW2
S16R Series
Mitsubishi S16R-A2PTAW2 65.370L V16 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: standby 1947 kWm at 1500 rpm, prime 1777 kWm at 1500 rpm. Emissions: U.S. EPA Tier 2 (standby); Unregulated (prime).
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,312 kVA
- Electrical Output
- 1,850 kWe
- Cylinders
- V16
- Displacement
- 65.37 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1777 | 1688 | 2110 |
| Standby Power | 1947 | 1849.6 | 2312 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S16R-A2PTAW2
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S16R-A2PTAW2 overhaul & repair parts
Already running a Mitsubishi S16R-A2PTAW2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Reviewed part-number references
A starting point for identification. Fitment must be confirmed before ordering.
- Turbocharger49182-06970
Turbocharger assembly
Fitment check: Match the exact MTEA Engine Type label S16R-A2PTAW2; use the complete engine serial number and current MEeS illustration to select among all listed turbocharger numbers before ordering
Source: Mitsubishi Turbocharger and Engine America official catalog - 49182-06970-Turbocharger
Selected references only; this is not a complete overhaul list or a stock listing.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S16R-A2PTAW2 and your selected categories included. Attach your photos there.
Mitsubishi S16R-A2PTAW2 generator set context
The Mitsubishi S16R-A2PTAW2 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,312 kVA / 1,850 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S16R-A2PTAW2 |
| Series | S16R Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 65.37 L |
| Dry Weight | 6710 kg |
| Dimensions (L×W×H) | 3046 × 1457 × 1810 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi S16R-A2PTAW2?
The Mitsubishi S16R-A2PTAW2 is rated at 2,312 kVA standby / 2,110 kVA prime at 50 Hz (1,500 rpm).
Does the S16R-A2PTAW2 run at 50 Hz or 60 Hz?
The Mitsubishi S16R-A2PTAW2 is rated for 50 Hz (1,500 rpm).
What fuel does the Mitsubishi S16R-A2PTAW2 use?
The Mitsubishi S16R-A2PTAW2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S16R-A2PTAW2?
The Mitsubishi S16R-A2PTAW2 is a V16 (16-cylinder) engine with a displacement of 65.37 L.
What emissions information is listed for the S16R-A2PTAW2?
This record lists U.S. EPA Tier 2 for the Mitsubishi S16R-A2PTAW2. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Mitsubishi S16R-A2PTAW2?
The Mitsubishi S16R-A2PTAW2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S16R-A2PTAW2?
This page links reference documents for the Mitsubishi S16R-A2PTAW2. Check each document's title, model coverage, revision and rating conditions before using it for selection.
