Mitsubishi
Mitsubishi S16R2-A2PTAW-C（T3）
S16R2 Series
The Mitsubishi S16R2-A2PTAW-C（T3） is a 46.56-litre V16 diesel engine for generator sets, rated at 2,438 kVA / 1,950 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 2,438 kVA
- Electrical Output
- 1,950 kWe
- Cylinders
- V16
- Displacement
- 46.56 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1960 | 1764 | 2205 |
| Standby Power | 2167 | 1950.3 | 2437.9 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | Mitsubishi |
| Model | S16R2-A2PTAW-C（T3） |
| Series | S16R2 Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 46.56 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Mitsubishi S16R2-A2PTAW-C（T3）?
The Mitsubishi S16R2-A2PTAW-C（T3） is rated at 2,438 kVA standby / 2,205 kVA prime at 50 Hz (1,500 rpm).
Does the S16R2-A2PTAW-C（T3） run at 50 Hz or 60 Hz?
The Mitsubishi S16R2-A2PTAW-C（T3） is rated for 50 Hz (1,500 rpm).
What fuel does the Mitsubishi S16R2-A2PTAW-C（T3） use?
The Mitsubishi S16R2-A2PTAW-C（T3） is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S16R2-A2PTAW-C（T3）?
The Mitsubishi S16R2-A2PTAW-C（T3） is a V16 (16-cylinder) engine with a displacement of 46.56 L.
Is the Mitsubishi S16R2-A2PTAW-C（T3） still in production?
Yes — the Mitsubishi S16R2-A2PTAW-C（T3） is a current production model.
Is a datasheet available for the S16R2-A2PTAW-C（T3）?
Yes — an official Mitsubishi datasheet for the Mitsubishi S16R2-A2PTAW-C（T3） can be downloaded from this page.
Related Engines
Compare Mitsubishi S16R2-A2PTAW-C（T3）
Reference
- Canonical page
- /engines/mitsubishi-s16r2-a2ptaw-c-t3
- Last database update
- 2026-05-29
- Manufacturer files
- 1 datasheet linked
