Mitsubishi S16R2-PTA-C
S16R2 Series
Mitsubishi S16R2-PTA-C 79.9L 16-cylinder Shanghai MHI generator-drive diesel engine. 1960 kWm prime and 2167 kWm standby at 50 Hz/1500 rpm.
Get help with this engine
Tell Haifeng whether you already own a Mitsubishi S16R2-PTA-C engine/generator or need to source this model for a project.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,573 kVA
- Electrical Output
- 2,059 kWe
- Cylinders
- V16
- Displacement
- 79.9 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1960 | 1862 | 2327.5 |
| Standby Power | 2167 | 2058.7 | 2573.4 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Mitsubishi S16R2-PTA-C generator set context
The Mitsubishi S16R2-PTA-C is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,573 kVA / 2,059 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S16R2-PTA-C |
| Series | S16R2 Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 79.9 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Mitsubishi S16R2-PTA-C?
The Mitsubishi S16R2-PTA-C is rated at 2,573 kVA standby / 2,328 kVA prime at 50 Hz (1,500 rpm).
Does the S16R2-PTA-C run at 50 Hz or 60 Hz?
The Mitsubishi S16R2-PTA-C is rated for 50 Hz (1,500 rpm).
What fuel does the Mitsubishi S16R2-PTA-C use?
The Mitsubishi S16R2-PTA-C is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S16R2-PTA-C?
The Mitsubishi S16R2-PTA-C is a V16 (16-cylinder) engine with a displacement of 79.9 L.
Is the Mitsubishi S16R2-PTA-C still in production?
Yes — the Mitsubishi S16R2-PTA-C is a current production model.
Is a datasheet available for the S16R2-PTA-C?
Yes — an official Mitsubishi datasheet for the Mitsubishi S16R2-PTA-C can be downloaded from this page.
