Mitsubishi
Mitsubishi S3L2-Z562SD
S3L2 Series
Mitsubishi S3L2-Z562SD 1.318L L3 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: prime 9.4 kWm at 1485 rpm, standby 10.5 kWm at 1485 rpm. Emissions: Euro Stage V.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 11 kVA
- Electrical Output
- 9 kWe
- Cylinders
- L3
- Displacement
- 1.318 L
- Rated Speed
- 1,485 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1485 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 9.4 | 8 | 10 |
| Standby Power | 10.5 | 9 | 11.2 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S3L2-Z562SD
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S3L2-Z562SD overhaul & repair parts
Already running a Mitsubishi S3L2-Z562SD? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S3L2-Z562SD and your selected categories included. Attach your photos there.
Mitsubishi S3L2-Z562SD generator set context
The Mitsubishi S3L2-Z562SD is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 11 kVA / 9 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S3L2-Z562SD |
| Series | S3L2 Series |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 1.318 L |
| Dry Weight | 150 kg |
| Dimensions (L×W×H) | 589 × 442 × 572 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi S3L2-Z562SD?
The Mitsubishi S3L2-Z562SD is rated at 11 kVA standby / 10 kVA prime at 50 Hz (1,485 rpm).
Does the S3L2-Z562SD run at 50 Hz or 60 Hz?
The Mitsubishi S3L2-Z562SD is rated for 50 Hz (1,485 rpm).
What fuel does the Mitsubishi S3L2-Z562SD use?
The Mitsubishi S3L2-Z562SD is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S3L2-Z562SD?
The Mitsubishi S3L2-Z562SD is an inline-3 (3-cylinder) engine with a displacement of 1.318 L.
What emissions information is listed for the S3L2-Z562SD?
This record lists Euro Stage V for the Mitsubishi S3L2-Z562SD. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Mitsubishi S3L2-Z562SD?
The Mitsubishi S3L2-Z562SD is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S3L2-Z562SD?
This page links reference documents for the Mitsubishi S3L2-Z562SD. Check each document's title, model coverage, revision and rating conditions before using it for selection.
