Mitsubishi S6A3-PTAA
Mitsubishi S6A3-PTAA 18.560L L6 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: standby 483 kWm at 1500 rpm, prime 440 kWm at 1500 rpm. Emissions: Unregulated.
Production StatusIn Production
S6A3 Series
- Configuration
- L6
- Displacement
- 18.56 L
- Fuel
- Diesel
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| Rating | Prime | Standby |
|---|---|---|
| Mechanical power kWm | 440 | 483 |
| Electrical output kWe | 418.4 | 459.2 |
| Apparent power kVA | 523 | 574 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Datasheet & documents
Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.
Technical specifications
Technical Specifications
| Brand | Mitsubishi |
| Model | S6A3-PTAA |
| Series | S6A3 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 18.56 L |
| Dry Weight | 1800 kg |
| Dimensions (L×W×H) | 2329 × 1542 × 1681 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Check your engine model
The Mitsubishi S6A3-PTAA is a diesel generator-drive engine for 50 Hz generator sets, rated at 574 kVA / 459 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
Other ways this model is written
s6a3ptaaS6A3 PTAAMitsubishi S6A3-PTAAS6A3 Series S6A3-PTAA
S6A3-PTAA repair parts
Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.
Get a parts & air-shipping quoteIn-stock parts: same-day dispatch
Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.
Find the right part
Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.
Other parts? Add them in the chat.
Get my parts quote on WhatsAppWe’ll confirm the correct parts, stock and delivery cost before you order.
Opens WhatsApp. Attach photos in the chat.
Photos and details to send
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
These categories have model-related records. Part numbers need further checking before we display them here.
Get help with this engine
Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.
Other ways to contact us
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamNeed help after checking the documents?
Send us the part number or describe the problem. This engine model is included in your message.
Send this model enquiry by emailOr browse Haifeng's diesel generator sets
Frequently asked questions
What is the power output of the Mitsubishi S6A3-PTAA?
The Mitsubishi S6A3-PTAA is rated at 574 kVA standby / 523 kVA prime at 50 Hz (1,500 rpm).
Does the S6A3-PTAA run at 50 Hz or 60 Hz?
The Mitsubishi S6A3-PTAA is rated for 50 Hz (1,500 rpm).
What fuel does the Mitsubishi S6A3-PTAA use?
The Mitsubishi S6A3-PTAA is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S6A3-PTAA?
The Mitsubishi S6A3-PTAA is an inline-6 (6-cylinder) engine with a displacement of 18.56 L.
What is the catalog status of the Mitsubishi S6A3-PTAA?
The Mitsubishi S6A3-PTAA is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S6A3-PTAA?
This page links reference documents for the Mitsubishi S6A3-PTAA. Check each document's title, model coverage, revision and rating conditions before using it for selection.
