Mitsubishi
Mitsubishi S6U2-PTA
S6U2 Series
Mitsubishi S6U2-PTA 81.430L L6 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: prime 1306 kWm at 1000 rpm, standby 1395 kWm at 1000 rpm; 60 Hz: prime 1194 kWm at 900 rpm, standby 1256 kWm at 900 rpm. Emissions: Unregulated.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,657 kVA
- Electrical Output
- 1,326 kWe
- Cylinders
- L6
- Displacement
- 81.43 L
- Rated Speed
- 900 / 1,080 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz900 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1306 | 1240.8 | 1551 |
| Standby Power | 1395 | 1325.6 | 1657 |
60 Hz1080 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1194 | 1134.4 | 1418 |
| Standby Power | 1256 | 1193.6 | 1492 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S6U2-PTA
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S6U2-PTA overhaul & repair parts
Already running a Mitsubishi S6U2-PTA? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S6U2-PTA and your selected categories included. Attach your photos there.
Mitsubishi S6U2-PTA generator set context
The Mitsubishi S6U2-PTA is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,657 kVA / 1,326 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S6U2-PTA |
| Series | S6U2 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 81.43 L |
| Dry Weight | 8650 kg |
| Dimensions (L×W×H) | 3402 × 1402 × 2206 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi S6U2-PTA?
The Mitsubishi S6U2-PTA is rated at 1,657 kVA standby / 1,551 kVA prime at 50 Hz (900 rpm); and 1,492 kVA standby / 1,418 kVA prime at 60 Hz (1,080 rpm).
Does the S6U2-PTA run at 50 Hz or 60 Hz?
The Mitsubishi S6U2-PTA is available for both 50 Hz (900 rpm) and 60 Hz (1,080 rpm).
What fuel does the Mitsubishi S6U2-PTA use?
The Mitsubishi S6U2-PTA is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S6U2-PTA?
The Mitsubishi S6U2-PTA is an inline-6 (6-cylinder) engine with a displacement of 81.43 L.
What is the catalog status of the Mitsubishi S6U2-PTA?
The Mitsubishi S6U2-PTA is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S6U2-PTA?
This page links reference documents for the Mitsubishi S6U2-PTA. Check each document's title, model coverage, revision and rating conditions before using it for selection.
