Mitsubishi
Mitsubishi S8U-PTA
S8U Series
Mitsubishi S8U-PTA 94.100L V8 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: prime 1619 kWm at 1000 rpm, standby 1678 kWm at 1000 rpm; 60 Hz: prime 1455 kWm at 900 rpm, standby 1503 kWm at 900 rpm, prime 1717 kWm at 1200 rpm, standby 1802 kWm at 1200 rpm. Emissions: Unregulated.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,993 kVA
- Electrical Output
- 1,594 kWe
- Cylinders
- V8
- Displacement
- 94.1 L
- Rated Speed
- 900 / 1,080 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz900 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1619 | 1538.4 | 1923 |
| Standby Power | 1678 | 1594.4 | 1993 |
60 Hz1080 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1717 | 1631.2 | 2039 |
| Standby Power | 1802 | 1712 | 2140 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S8U-PTA
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S8U-PTA overhaul & repair parts
Already running a Mitsubishi S8U-PTA? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S8U-PTA and your selected categories included. Attach your photos there.
Mitsubishi S8U-PTA generator set context
The Mitsubishi S8U-PTA is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,993 kVA / 1,594 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S8U-PTA |
| Series | S8U Series |
| Configuration | V8 |
| Cylinders | 8 |
| Displacement | 94.1 L |
| Dry Weight | 11000 kg |
| Dimensions (L×W×H) | 4226 × 1538 × 2191 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi S8U-PTA?
The Mitsubishi S8U-PTA is rated at 1,993 kVA standby / 1,923 kVA prime at 50 Hz (900 rpm); and 2,140 kVA standby / 2,039 kVA prime at 60 Hz (1,080 rpm).
Does the S8U-PTA run at 50 Hz or 60 Hz?
The Mitsubishi S8U-PTA is available for both 50 Hz (900 rpm) and 60 Hz (1,080 rpm).
What fuel does the Mitsubishi S8U-PTA use?
The Mitsubishi S8U-PTA is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S8U-PTA?
The Mitsubishi S8U-PTA is a V8 (8-cylinder) engine with a displacement of 94.1 L.
What is the catalog status of the Mitsubishi S8U-PTA?
The Mitsubishi S8U-PTA is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S8U-PTA?
This page links reference documents for the Mitsubishi S8U-PTA. Check each document's title, model coverage, revision and rating conditions before using it for selection.
