MTU 10V1600G20
Series 1600
MTU 10V1600G20 17.5L 10-cylinder diesel engine for generator sets. 447 kWe standby at 50Hz / 508 kWe at 60Hz. U.S. EPA Tier 2. Turbocharged Intercooled.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 559 kVA
- Electrical Output
- 447 kWe
- Cylinders
- V10
- Displacement
- 17.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 451.1 | 406 | 507.5 |
| Standby Power | 496.7 | 447 | 558.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 514.4 | 463 | 578.8 |
| Standby Power | 564.4 | 508 | 635 |
Ask about MTU 10V1600G20
Choose parts / service or sourcing. Your message includes this model and page link.
MTU 10V1600G20 overhaul & repair parts
Already running a MTU 10V1600G20? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 10V1600G20 and your selected categories included. Attach your photos there.
MTU 10V1600G20 generator set context
The MTU 10V1600G20 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 559 kVA / 447 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | MTU |
| Model | 10V1600G20 |
| Series | Series 1600 |
| Configuration | V10 |
| Cylinders | 10 |
| Displacement | 17.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the MTU 10V1600G20?
The MTU 10V1600G20 is rated at 559 kVA standby / 508 kVA prime at 50 Hz (1,500 rpm); and 635 kVA standby / 579 kVA prime at 60 Hz (1,800 rpm).
Does the 10V1600G20 run at 50 Hz or 60 Hz?
The MTU 10V1600G20 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the MTU 10V1600G20 use?
The MTU 10V1600G20 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 10V1600G20?
The MTU 10V1600G20 is a V10 (10-cylinder) engine with a displacement of 17.5 L.
What emissions information is listed for the 10V1600G20?
This record lists U.S. EPA Tier 2 for the MTU 10V1600G20. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the MTU 10V1600G20?
The MTU 10V1600G20 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 10V1600G20?
This page links reference documents for the MTU 10V1600G20. Check each document's title, model coverage, revision and rating conditions before using it for selection.
