MTU
MTU MTU 16V4000 G24F
4000 Series
The MTU MTU 16V4000 G24F is a 76.3-litre V16 diesel engine for generator sets, rated at 2,433 kVA / 1,946 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in Germany.
- Standby Power · 50 Hz
- 2,433 kVA
- Electrical Output
- 1,946 kWe
- Cylinders
- V16
- Displacement
- 76.3 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1965.6 | 1769 | 2211.3 |
| Standby Power | 2162.2 | 1946 | 2432.5 |
Technical Specifications
| Brand | MTU |
| Model | MTU 16V4000 G24F |
| Series | 4000 Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 76.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the MTU MTU 16V4000 G24F?
The MTU MTU 16V4000 G24F is rated at 2,433 kVA standby / 2,211 kVA prime at 50 Hz (1,500 rpm).
Does the MTU 16V4000 G24F run at 50 Hz or 60 Hz?
The MTU MTU 16V4000 G24F is rated for 50 Hz (1,500 rpm).
What fuel does the MTU MTU 16V4000 G24F use?
The MTU MTU 16V4000 G24F is a diesel generator-set engine.
What is the displacement and cylinder configuration of the MTU 16V4000 G24F?
The MTU MTU 16V4000 G24F is a V16 (16-cylinder) engine with a displacement of 76.3 L.
Is the MTU MTU 16V4000 G24F still in production?
Yes — the MTU MTU 16V4000 G24F is a current production model.
Is a datasheet available for the MTU 16V4000 G24F?
Yes — an official MTU datasheet for the MTU MTU 16V4000 G24F can be downloaded from this page.
