MTU
MTU MTU 16V4000 G63
4000 Series
The MTU MTU 16V4000 G63 is a 76.3-litre V16 diesel engine for generator sets, rated at 2,433 kVA / 1,946 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in Germany.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,433 kVA
- Electrical Output
- 1,946 kWe
- Cylinders
- V16
- Displacement
- 76.3 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1965.6 | 1769 | 2211.3 |
| Standby Power | 2162.2 | 1946 | 2432.5 |
Ask about MTU MTU 16V4000 G63
Choose parts / service or sourcing. Your message includes this model and page link.
MTU MTU 16V4000 G63 overhaul & repair parts
Already running a MTU MTU 16V4000 G63? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with MTU 16V4000 G63 and your selected categories included. Attach your photos there.
MTU MTU 16V4000 G63 generator set context
The MTU MTU 16V4000 G63 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,433 kVA / 1,946 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | MTU |
| Model | MTU 16V4000 G63 |
| Series | 4000 Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 76.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the MTU MTU 16V4000 G63?
The MTU MTU 16V4000 G63 is rated at 2,433 kVA standby / 2,211 kVA prime at 50 Hz (1,500 rpm).
Does the MTU 16V4000 G63 run at 50 Hz or 60 Hz?
The MTU MTU 16V4000 G63 is rated for 50 Hz (1,500 rpm).
What fuel does the MTU MTU 16V4000 G63 use?
The MTU MTU 16V4000 G63 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the MTU 16V4000 G63?
The MTU MTU 16V4000 G63 is a V16 (16-cylinder) engine with a displacement of 76.3 L.
What is the catalog status of the MTU MTU 16V4000 G63?
The MTU MTU 16V4000 G63 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the MTU 16V4000 G63?
This page links reference documents for the MTU MTU 16V4000 G63. Check each document's title, model coverage, revision and rating conditions before using it for selection.
