MTU
MTU MTU 20V4000 G83
4000 Series
MTU 20V4000 G83 is a 95.332 L V20 diesel engine. EPA records list 3B, 3D and 3F configurations from 2740 to 3010 kWm at 1800 RPM under Tier 2.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-07-25
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 3,386 kVA
- Electrical Output
- 2,709 kWe
- Cylinders
- V20
- Displacement
- 95.332 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 3010 | 2709 | 3386.3 |
Ask about MTU MTU 20V4000 G83
Choose parts / service or sourcing. Your message includes this model and page link.
MTU MTU 20V4000 G83 overhaul & repair parts
Already running a MTU MTU 20V4000 G83? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with MTU 20V4000 G83 and your selected categories included. Attach your photos there.
MTU MTU 20V4000 G83 generator set context
The MTU MTU 20V4000 G83 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 3,386 kVA / 2,709 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | MTU |
| Model | MTU 20V4000 G83 |
| Series | 4000 Series |
| Configuration | V20 Turbocharged Intercooled |
| Cylinders | 20 |
| Displacement | 95.332 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Certifications | U.S. EPA Tier 2 |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the MTU MTU 20V4000 G83?
The MTU MTU 20V4000 G83 is rated at 3,386 kVA standby at 60 Hz (1,800 rpm).
Does the MTU 20V4000 G83 run at 50 Hz or 60 Hz?
The MTU MTU 20V4000 G83 is rated for 60 Hz (1,800 rpm).
What fuel does the MTU MTU 20V4000 G83 use?
The MTU MTU 20V4000 G83 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the MTU 20V4000 G83?
The MTU MTU 20V4000 G83 is a V20 (20-cylinder) engine with a displacement of 95.332 L.
What emissions information is listed for the MTU 20V4000 G83?
This record lists U.S. EPA Tier 2 for the MTU MTU 20V4000 G83. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the MTU MTU 20V4000 G83?
The MTU MTU 20V4000 G83 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the MTU 20V4000 G83?
This page links reference documents for the MTU MTU 20V4000 G83. Check each document's title, model coverage, revision and rating conditions before using it for selection.
