MTU
MTU 20V4000 GS
Series 4000
MTU 20V4000 GS — 95.3 L V20 (170 × 210 mm) lean-burn spark-ignited natural-gas GenDrive engine (mtu Series 4000). 1948–2535 kWe across L32/L33/L64 ratings at 1500 rpm / 50 Hz, electrical efficiency up to ~44%; NOx < 500 mg/Nm³.
- Prime Power · 50 Hz
- 3,169 kVA
- Electrical Output
- 2,535 kWe
- Cylinders
- V20
- Displacement
- 95.3 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 2535 | 3168.8 |
Technical Specifications
| Brand | MTU |
| Model | 20V4000 GS |
| Series | Series 4000 |
| Configuration | V20 |
| Cylinders | 20 |
| Displacement | 95.3 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
