Perkins
Perkins 1206J-E70TTAG4
1200 Series
Perkins 1206J-E70TTAG4 7.01 L L6 ElectropaK diesel engine for generator sets. At 60 Hz and 1800 RPM, Perkins publishes 208 kWm net / 180 kWe prime and 229 kWm net / 200 kWe standby. Euro Stage V / U.S. EPA Final Tier 4.
Overhaul & repair parts- Supporting documents
- 2 documents · 2 datasheets
- Last updated
- 2026-07-25
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 219 kVA
- Electrical Output
- 175 kWe
- Cylinders
- L6
- Displacement
- 7.01 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 176.7 | 159 | 198.8 |
| Standby Power | 194.4 | 175 | 218.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 208 | 180 | 225 |
| Standby Power | 229 | 200 | 250 |
Ask about Perkins 1206J-E70TTAG4
Choose parts / service or sourcing. Your message includes this model and page link.
Perkins 1206J-E70TTAG4 overhaul & repair parts
Already running a Perkins 1206J-E70TTAG4? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 1206J-E70TTAG4 and your selected categories included. Attach your photos there.
Perkins 1206J-E70TTAG4 generator set context
The Perkins 1206J-E70TTAG4 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 219 kVA / 175 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Perkins |
| Model | 1206J-E70TTAG4 |
| Series | 1200 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.01 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V / U.S. EPA Final Tier 4 |
| Certifications | Euro Stage V, U.S. EPA Final Tier 4 |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the Perkins 1206J-E70TTAG4?
The Perkins 1206J-E70TTAG4 is rated at 219 kVA standby / 199 kVA prime at 50 Hz (1,500 rpm); and 250 kVA standby / 225 kVA prime at 60 Hz (1,800 rpm).
Does the 1206J-E70TTAG4 run at 50 Hz or 60 Hz?
The Perkins 1206J-E70TTAG4 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 1206J-E70TTAG4 use?
The Perkins 1206J-E70TTAG4 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 1206J-E70TTAG4?
The Perkins 1206J-E70TTAG4 is an inline-6 (6-cylinder) engine with a displacement of 7.01 L.
What emissions information is listed for the 1206J-E70TTAG4?
This record lists Euro Stage V / U.S. EPA Final Tier 4 for the Perkins 1206J-E70TTAG4. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Perkins 1206J-E70TTAG4?
The Perkins 1206J-E70TTAG4 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 1206J-E70TTAG4?
This page links reference documents for the Perkins 1206J-E70TTAG4. Check each document's title, model coverage, revision and rating conditions before using it for selection.
