Perkins
Perkins 1706J-E93TAG2
1700 Series
The Perkins 1706J-E93TAG2 is a 9.3-litre inline-6 diesel engine for generator sets, rated at 344 kVA / 275 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in United Kingdom. It meets Euro Stage V / U.S. EPA Final Tier 4 emissions standards.
Chat on WhatsApp about this engine
Opens WhatsApp with Perkins 1706J-E93TAG2 and this page link filled in.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 344 kVA
- Electrical Output
- 275 kWe
- Cylinders
- L6
- Displacement
- 9.3 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 276.7 | 249 | 311.3 |
| Standby Power | 305.6 | 275 | 343.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 296.7 | 267 | 333.8 |
| Standby Power | 328.9 | 296 | 370 |
Perkins 1706J-E93TAG2 generator set context
The Perkins 1706J-E93TAG2 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 344 kVA / 275 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Perkins |
| Model | 1706J-E93TAG2 |
| Series | 1700 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 9.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V / U.S. EPA Final Tier 4 |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the Perkins 1706J-E93TAG2?
The Perkins 1706J-E93TAG2 is rated at 344 kVA standby / 311 kVA prime at 50 Hz (1,500 rpm); and 370 kVA standby / 334 kVA prime at 60 Hz (1,800 rpm).
Does the 1706J-E93TAG2 run at 50 Hz or 60 Hz?
The Perkins 1706J-E93TAG2 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 1706J-E93TAG2 use?
The Perkins 1706J-E93TAG2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 1706J-E93TAG2?
The Perkins 1706J-E93TAG2 is an inline-6 (6-cylinder) engine with a displacement of 9.3 L.
What emissions standard does the 1706J-E93TAG2 meet?
The Perkins 1706J-E93TAG2 is certified to Euro Stage V / U.S. EPA Final Tier 4 emissions standards.
Is the Perkins 1706J-E93TAG2 still in production?
Yes — the Perkins 1706J-E93TAG2 is a current production model.
Is a datasheet available for the 1706J-E93TAG2?
Yes — an official Perkins datasheet for the Perkins 1706J-E93TAG2 can be downloaded from this page.
