Perkins
Perkins 2206F-E13TAG2
Source-checked against user-supplied Perkins manufacturer datasheets: 1500 rpm: gross mechanical prime 317 kW / standby 351 kW; 1800 rpm: gross mechanical prime 384 kW / standby 421 kW. Sources: 2206F-E13TAG2 Switchable TPD2139 February 2018.pdf p.2. Catalogue power_kw is the highest documented standby rating; individual frequency/duty fields preserve the source ratings. Electrical genset output and emissions certification have not been inferred. Production status is unknown. Discontinued is the user-authorized catalogue classification (2026-10-21 import), not manufacturer-confirmed cessation; no production-end year is asserted.
Need parts or a replacement for 2206F-E13TAG2?
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-10-21
- Package route
- diesel generator sets
- Mechanical Output
- 351 kW
- Cylinders
- L6
- Displacement
- 12.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 317 | — | — |
| Standby Power | 351 | — | — |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 384 | — | — |
| Standby Power | 421 | — | — |
Estimated rating: 315.9 kWe (351 kW × 0.90) · 50 Hz · standby
Estimated rating: 285.3 kWe (317 kW × 0.90) · 50 Hz · prime
Estimated rating: 378.9 kWe (421 kW × 0.90) · 60 Hz · standby
Estimated rating: 345.6 kWe (384 kW × 0.90) · 60 Hz · prime
Planning estimate, not a manufacturer generator rating. Confirm the alternator, engine speed and operating conditions.
Perkins 2206F-E13TAG2 overhaul & repair parts
Need help identifying a part for your 2206F-E13TAG2?
Share your nameplate, parts list and destination for a quote.
Identify my part on WhatsAppAvailability and earliest dispatch confirmed for your enquiry.
Opens WhatsApp. Attach photos in the chat.
What to send for a fitment check
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Illustrations only — not a model-specific kit or stock confirmation.
View 2206F-E13TAG2 spec image
Perkins 2206F-E13TAG2 generator set context
The Perkins 2206F-E13TAG2 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 351 kW / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Model name formats
Technical Specifications
| Brand | Perkins |
| Model | 2206F-E13TAG2 |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 12.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
Frequently asked questions
Does the 2206F-E13TAG2 run at 50 Hz or 60 Hz?
The Perkins 2206F-E13TAG2 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 2206F-E13TAG2 use?
The Perkins 2206F-E13TAG2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 2206F-E13TAG2?
The Perkins 2206F-E13TAG2 is an inline-6 (6-cylinder) engine with a displacement of 12.5 L.
Is the 2206F-E13TAG2 still in production?
No — the Perkins 2206F-E13TAG2 is discontinued. Its specifications and datasheets remain archived here for reference.
Are reference documents available for the 2206F-E13TAG2?
This page links reference documents for the Perkins 2206F-E13TAG2. Check each document's title, model coverage, revision and rating conditions before using it for selection.
