Perkins
Perkins 2406J-E13TAG3
2400 Series
The Perkins 2406J-E13TAG3 is a 13-litre inline-6 diesel engine for generator sets, rated at 453 kVA / 362 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in United Kingdom. It meets Euro Stage V / U.S. EPA Final Tier 4 emissions standards.
- Standby Power · 50 Hz
- 453 kVA
- Electrical Output
- 362 kWe
- Cylinders
- L6
- Displacement
- 13 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 364.4 | 328 | 410 |
| Standby Power | 402.2 | 362 | 452.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 380 | 342 | 427.5 |
| Standby Power | 421.1 | 379 | 473.8 |
Technical Specifications
| Brand | Perkins |
| Model | 2406J-E13TAG3 |
| Series | 2400 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 13 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V / U.S. EPA Final Tier 4 |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the Perkins 2406J-E13TAG3?
The Perkins 2406J-E13TAG3 is rated at 453 kVA standby / 410 kVA prime at 50 Hz (1,500 rpm); and 474 kVA standby / 428 kVA prime at 60 Hz (1,800 rpm).
Does the 2406J-E13TAG3 run at 50 Hz or 60 Hz?
The Perkins 2406J-E13TAG3 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 2406J-E13TAG3 use?
The Perkins 2406J-E13TAG3 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 2406J-E13TAG3?
The Perkins 2406J-E13TAG3 is an inline-6 (6-cylinder) engine with a displacement of 13 L.
What emissions standard does the 2406J-E13TAG3 meet?
The Perkins 2406J-E13TAG3 is certified to Euro Stage V / U.S. EPA Final Tier 4 emissions standards.
Is the Perkins 2406J-E13TAG3 still in production?
Yes — the Perkins 2406J-E13TAG3 is a current production model.
Is a datasheet available for the 2406J-E13TAG3?
Yes — an official Perkins datasheet for the Perkins 2406J-E13TAG3 can be downloaded from this page.
