Perkins
Perkins 3.1524
3.152 Series
Perkins 3.1524 discontinued legacy engine. The 3.1524 ElectropaK is a 3-cylinder generator-drive derivative of the long-running Perkins 3.152 lineage, useful for owners searching old small genset, farm, welder, pump, and parts applications. Model identity and technical fields are taken from Perkins-era specification sheets archived by Diesel Parts Direct; legacy status is cross-checked against Perkins heritage material and parts-support references.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-08-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 30 kVA
- Electrical Output
- 24 kWe
- Cylinders
- L3
- Displacement
- 2.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 25 | 22 | — |
| Standby Power | 27.5 | 24 | — |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 28 | 24.5 | — |
| Standby Power | 31 | 27 | — |
Ask about Perkins 3.1524
Choose parts / service or sourcing. Your message includes this model and page link.
Perkins 3.1524 overhaul & repair parts
Already running a Perkins 3.1524? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 3.1524 and your selected categories included. Attach your photos there.
Perkins 3.1524 generator set context
The Perkins 3.1524 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 30 kVA / 24 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Perkins |
| Model | 3.1524 |
| Series | 3.152 Series |
| Configuration | L3, naturally aspirated generator-drive diesel |
| Cylinders | 3 |
| Displacement | 2.5 L |
| Compression Ratio | 16.5:1 |
| Dry Weight | 311 kg |
| Dimensions (L×W×H) | 940 × 620 × 846 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | United Kingdom |
| Year Discontinued | 2005 |
Frequently asked questions
What is the power output of the Perkins 3.1524?
The Perkins 3.1524 is rated at 30 kVA standby / 28 kVA prime at 50 Hz (1,500 rpm); and 34 kVA standby / 31 kVA prime at 60 Hz (1,800 rpm).
Does the 3.1524 run at 50 Hz or 60 Hz?
The Perkins 3.1524 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 3.1524 use?
The Perkins 3.1524 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 3.1524?
The Perkins 3.1524 is an inline-3 (3-cylinder) engine with a displacement of 2.5 L.
Is the 3.1524 still in production?
No — the Perkins 3.1524 is discontinued (production ended around 2005). Its specifications and datasheets remain archived here for reference.
Are reference documents available for the 3.1524?
This page links reference documents for the Perkins 3.1524. Check each document's title, model coverage, revision and rating conditions before using it for selection.
