Perkins
Perkins 403D-07
Source-checked against user-supplied Perkins manufacturer datasheets: 1500 rpm: gross mechanical prime 5.5 kW / standby 6 kW; 1800 rpm: gross mechanical prime 6.7 kW / standby 7.4 kW. Sources: 403D-07 6.0kW@1500rpm TPD2021 July 2017.pdf p.2; 403D-07 7.4kW@1800 TPD2111 September 2017.pdf p.2. Catalogue power_kw is the highest documented standby rating; individual frequency/duty fields preserve the source ratings. Electrical genset output and emissions certification have not been inferred. Production status is unknown. Discontinued is the user-authorized catalogue classification (2026-10-21 import), not manufacturer-confirmed cessation; no production-end year is asserted.
Need parts or a replacement for 403D-07?
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team- Supporting documents
- 2 documents · 2 datasheets
- Last updated
- 2026-10-21
- Package route
- diesel generator sets
- Mechanical Output
- 6 kW
- Cylinders
- L3
- Displacement
- 0.761 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 5.5 | — | — |
| Standby Power | 6 | — | — |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 6.7 | — | — |
| Standby Power | 7.4 | — | — |
Estimated rating: 5.4 kWe (6 kW × 0.90) · 50 Hz · standby
Estimated rating: 5 kWe (5.5 kW × 0.90) · 50 Hz · prime
Estimated rating: 6.7 kWe (7.4 kW × 0.90) · 60 Hz · standby
Estimated rating: 6 kWe (6.7 kW × 0.90) · 60 Hz · prime
Planning estimate, not a manufacturer generator rating. Confirm the alternator, engine speed and operating conditions.
Perkins 403D-07 overhaul & repair parts
Need help identifying a part for your 403D-07?
Share your nameplate, parts list and destination for a quote.
Identify my part on WhatsAppAvailability and earliest dispatch confirmed for your enquiry.
Opens WhatsApp. Attach photos in the chat.
What to send for a fitment check
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Illustrations only — not a model-specific kit or stock confirmation.
View 403D-07 spec image
Perkins 403D-07 generator set context
The Perkins 403D-07 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 6 kW / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Model name formats
Technical Specifications
| Brand | Perkins |
| Model | 403D-07 |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 0.761 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
Frequently asked questions
Does the 403D-07 run at 50 Hz or 60 Hz?
The Perkins 403D-07 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 403D-07 use?
The Perkins 403D-07 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 403D-07?
The Perkins 403D-07 is an inline-3 (3-cylinder) engine with a displacement of 0.761 L.
Is the 403D-07 still in production?
No — the Perkins 403D-07 is discontinued. Its specifications and datasheets remain archived here for reference.
Are reference documents available for the 403D-07?
This page links reference documents for the Perkins 403D-07. Check each document's title, model coverage, revision and rating conditions before using it for selection.
