Perkins
Perkins 404J-22G
400 Series
The Perkins 404J-22G is a 2.2-litre inline-4 diesel engine for generator sets, rated at 23 kVA / 18 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China. It meets Euro Stage V / U.S. EPA Final Tier 4 emissions standards.
Overhaul & repair parts- Supporting documents
- 2 documents · 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 23 kVA
- Electrical Output
- 18 kWe
- Cylinders
- L4
- Displacement
- 2.2 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 17.8 | 16 | 20 |
| Standby Power | 20 | 18 | 22.5 |
Ask about Perkins 404J-22G
Choose parts / service or sourcing. Your message includes this model and page link.
Perkins 404J-22G overhaul & repair parts
Already running a Perkins 404J-22G? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 404J-22G and your selected categories included. Attach your photos there.
Perkins 404J-22G generator set context
The Perkins 404J-22G is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 23 kVA / 18 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Perkins |
| Model | 404J-22G |
| Series | 400 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 2.2 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V / U.S. EPA Final Tier 4 |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Perkins 404J-22G?
The Perkins 404J-22G is rated at 23 kVA standby / 20 kVA prime at 50 Hz (1,500 rpm).
Does the 404J-22G run at 50 Hz or 60 Hz?
The Perkins 404J-22G is rated for 50 Hz (1,500 rpm).
What fuel does the Perkins 404J-22G use?
The Perkins 404J-22G is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 404J-22G?
The Perkins 404J-22G is an inline-4 (4-cylinder) engine with a displacement of 2.2 L.
What emissions information is listed for the 404J-22G?
This record lists Euro Stage V / U.S. EPA Final Tier 4 for the Perkins 404J-22G. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Perkins 404J-22G?
The Perkins 404J-22G is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 404J-22G?
This page links reference documents for the Perkins 404J-22G. Check each document's title, model coverage, revision and rating conditions before using it for selection.
